Belt & Hose Reinforcement Yarn: Bondcoat™ Adhesion
FIBER-LINE® produces various twisted and corded products for reinforcement in drive/timing belts and hoses. These products have high-strength, low stretch, and excellent fatigue properties. FIBER-LINE® twisted and corded products are properly torque-balanced for optimal performance.
Key Features of FIBER-LINE® Belt & Hose Yarn:
- Flexible & lightweight reinforcements
- Limited elongation & high strength
- Various twisted & corded constructions available
- Significantly reduce fraying during processing
- Metered lengths available
FIBER-LINE® Bondcoat products were created for applications where an untreated fiber does not have the ability to provide the appropriate amount of bonding characteristics to another material.
Fibers for Belt & Hose Reinforcement:
Performance Adding Coatings:
- FIBER-LINE® Bondcoat™: Adhesion promotors
Packaging
FIBER-LINE® Belt & Hose Yarn is supplied on a variety of cardboard tubes to meet your equipment needs. Packages can be supplied on colored, embossed and/or slit tubes. Plastic, wood, or metal reels are also available. Contact us today with dimensions you require.
Popular Products
| Product ID | Fiber-Line Coating | Base fiber | Nominal Break strength | Nominal Yield | Nominal Diameter | Description |
|---|---|---|---|---|---|---|
| FG2039 | FIBER-LINE® Bondcoat™ | Kevlar® | 19 kg | 8725 m/kg | 0.374 mm | Twisted Kevlar® fiber coated with heat-activated adhesive coating |
| FG2000 | FIBER-LINE® Bondcoat™ | Kevlar® | 45 kg | 3928 m/kg | 0.558 mm | Twisted Kevlar® fiber coated with heat-activated adhesive coating |
| FG1706 | FIBER-LINE® Bondcoat™ | Kevlar® | 180 kg | 917 m/kg | 1.22 mm | High twist Kevlar® cord coated with heat-activated adhesive coating |
| FG2199 | FIBER-LINE® Bondcoat™ | Vectran® | 250 kg | 920 m/kg | 1.31 mm | Twisted Vectran® cord coated with adhesion promoting coating |
This data is provided for informational purposes only, and does not constitute a specification. FIBER-LINE makes no warranty, express or implied, that the product conforms to these values. Contact your FIBER-LINE representative for exact product details which conform to your specific requirements.
